Overview

API to generate e-Invoice using the details passed in the request body and return the Invoice Registration Number irn

Endpoint

HTTP Method	Resource
`POST`

Request

Follow the below guidelines to pass GSTIN in the path parameter and invoice details in the request body to generate IRN.

Headers

Param	Type	Description	Example
x-api-key	`string`	An API key is a public key to identify users when calling any Sandbox API.	key_live_ZUQT5UEf4......
Authorization	`string`	JWT Authorization token which is generated using e-Invoice Authentication API.	eyJhsebihGyUf......

Body Parameters

Param	Type	Description
Version	`object`	Version of the schema
TranDtls	`json object`	Transaction Details
DocDtls	`json object`	Document/Invoice Details
SellerDtls	`json object`	Supplier Details
BuyerDtls	`json object`	Buyer Details
DispDtls	`json object`	Dispatch Details
ShipDtls	`json object`	Shipping Details
ItemList	`json object`	Item Lists
ValDtls	`json object`	Invoice Value Details
PayDtls	`json object`	Payment Details
RefDtls	`json object`	Reference Details
PrecDocDtls	`json object`	Preceding Document Details
ContrDtls	`json object`	Contract Details
AddlDocDtls	`json object`	Additional Document Details
ExpDtls	`json object`	Export Details
EwbDtls	`json object`	E-Way Bill Details

Transaction Details

Param	Type	Description	Example
TaxSch	`string`	GST- Goods and Services Tax Scheme	GST
SupTyp	`string`	Type of Supply: `B2B`-Business to Business, `SEZWP` - SEZ with payment, `SEZWOP` - SEZ without payment, `EXPWP` - Export with Payment, `EXPWOP` - Export without payment, `DEXP` - Deemed Export	B2B
RegRev	`string`	whether the tax liability is payable under reverse charge. Possible values: `Y` or `N`	Y
EcmGstin	`string`	GSTIN of e-Commerce operator	null
IgstOnIntra	`string`	Supply is intra-state and chargeable to IGST. Possible Values: `Y` or `N`	N

Document/Invoice Details

Param	Type	Description	Example
Typ	`string`	Document Type: `INV` - INVOICE `CRN` - CREDIT NOTE `DBN` - DEBIT NOTE	INV
No	`string`	Document Number	DOC/001
Dt	`string`	Document Date	18/08/2020

Seller Details

Param	Type	Description	Example
Gstin	`string`	GSTIN of supplier	37ARZPT4384Q1MT
LglNm	`string`	Legal Name	NIC company pvt ltd
TrdNm	`string`	Tradename	NIC Industries
Addr1	`string`	Building/Flat no, Road/Street	5th block, kuvempu layout
Addr2	`string`	Address 2 of the supplier (Floor no., Name of the premises/building)	kuvempu layout
Loc	`string`	Location	GANDHINAGAR
Pin	`string`	Pincode	518001
Stcd	`string`	State Code of the supplier	37
Ph	`string`	Phone or Mobile No	9000000000
Em	`string`	Email-Id	[email protected]

Buyer Details

Param	Type	Description	Example
Gstin	`string`	GSTIN of Buyer, URP if exporting	29AWGPV7107B1Z1
LglNm	`string`	Legal Name	XYZ company pvt ltd
TrdNm	`string`	Tradename	XYZ Industries
Pos	`string`	State code of Place of supply. If POS lies outside the country, the code shall be 96.	12
Addr1	`string`	Address 1 of the buyer. (Building/Flat no., Road/Street etc.)	7th block, kuvempu layout
Addr2	`string`	Address 2 of the buyer. (Floor no., Name of the premises/ building)	kuvempu layout
Loc	`string`	Location	GANDHINAGAR
Pin	`string`	Pincode	562160
Stcd	`string`	State Code of the buyer	29
Ph	`string`	Phone or Mobile No	91111111111
Em	`string`	Email-Id	[email protected]

Dispatch Details

Param	Type	Description	Example
Nm	`string`	Name of the company from which the goods are dispatched	ABC company pvt ltd
Addr1	`string`	Address 1 of the entity from which goods are dispatched. (Building/Flat no.Road/Street etc.)	7th block, kuvempu layout
Addr2	`string`	Address 2 of the entity from which goods are dispatched. (Floor no., Name of the premises/building)	kuvempu layout
Loc	`string`	Location	Banagalore
Pin	`string`	Pincode	562160
Stcd	`string`	State Code from where goods are dispatched.	29

Shipping Details

Param	Type	Description	Example
Gstin	`string`	GSTIN of entity to whom goods are shipped	29AWGPV7107B1Z1
LglNm	`string`	Legal Name	CBE company pvt ltd
TrdNm	`string`	Trade Name	kuvempu layout
Addr1	`string`	Address1 of the entity to whom the supplies are shipped to. (Building/Flat no., Road/Street etc.)	7th block, kuvempu layout
Addr2	`string`	Address 2 of the entity to whom the supplies are shipped to. (Floor no., Name of the premises/building).	kuvempu layout
Loc	`string`	Place (City,Town,Village) entity to whom the supplies are shipped to.	Banagalore
Pin	`string`	Pincode	562160
Stcd	`string`	State Code to which supplies are shipped to	29

Item List

Param	Type	Description	Example
SlNo	`string`	Serial No. of Item	1
PrdDesc	`string`	Product Description	Rice
IsServc	`string`	Specify whether the supply is service or not. `Y`- Service, `N` - Not service	N
HsnCd	`string`	HSN Code	1001
Barcde	`string`	Bar Code	123456
Qty	`string`	Quantity	100.35
FreeQty	`string`	Free Quantity	10
Unit	`string`	Unit	BAG
UnitPrice	`string`	Unit Price - Rate	99.545
TotAmt	`string`	Gross Amount (Unit Price * Quantity)	9988.84
Discount	`string`	Discount	10
PreTaxVal	`string`	Pre tax value	1
AssAmt	`string`	Taxable Value (Total Amount -Discount)	9978.84
GstRt	`string`	The GST rate, represented as percentage that applies to the invoiced item. It will IGST rate only.	12.0
IgstAmt	`string`	Amount of IGST payable	1197.46
CgstAmt	`string`	Amount of CGST payable	0
SgstAmt	`string`	Amount of SGST payable	0
CesRt	`string`	Cess Rate	5
CesAmt	`string`	Cess Amount(Advalorem) on basis of rate and quantity of item	498.94
CesNonAdvlAmt	`string`	Cess Non-Advol Amount	10
StateCesRt	`string`	State CESS Rate	12
StateCesAmt	`string`	State CESS Amount	1197.46
StateCesNonAdvlAmt	`string`	State CESS Non Adval Amount	5
OthChrg	`string`	Other Charges	10
TotItemVal	`string`	Total Item Value = Assessable Amount + CGST Amt + SGST Amt + Cess Amt + CesNonAdvlAmt + StateCesAmt + StateCesNonAdvlAmt+Otherchrg	12897.7
OrdLineRef	`string`	Order line reference	3256
OrgCntry	`string`	Origin Country.	AG
PrdSlNo	`string`	Serial number in case of each item having a unique number	12345
BchDtls	`json object`	Batch Details
AttribDtls	`json object`	Attribute Details

Batch Details

Param	Type	Description	Example
Nm	`string`	Batch number	123456
ExpDt	`string`	Batch Expiry Date	01/08/2020
WrDt	`string`	Warranty Date	01/09/2020

Attribute Details

Param	Type	Description	Example
Nm	`string`	Attribute name of the item	Rice
Val	`string`	Attribute value of the item	10000

Invoice Value Details

Param	Type	Description	Example
AssVal	`string`	Total Assessable value of all items	9978.84
CgstVal	`string`	Total CGST value of all items	0
SgstVal	`string`	Total SGST value of all items	0
IgstVal	`string`	Total IGST value of all items	1197.46
CesVal	`string`	Total CESS value of all items	508.94
StCesVal	`string`	Total State CESS value of all items	1202.46
Discount	`string`	Discount	10
OthChrg	`string`	Other Charges	20
RndOffAmt	`string`	Rounded off amount	0.3
TotInvVal	`string`	Final Invoice value	12908
TotInvValFc	`string`	Final Invoice value in Additional Currency	12897.7

Payment Details

Param	Type	Description	Example
Nm	`string`	Payee Name	ABCDE
AccDet	`string`	Bank account number of payee	5697389713210
Mode	`string`	Mode of Payment: Cash, Credit, Direct Transfer	Cash
FinInsBr	`string`	Branch or IFSC code	SBIN11000
PayTerm	`string`	Terms of Payment	100
PayInstr	`string`	Payment Instruction	Gift
CrTrn	`string`	Credit Transfer	test
DirDr	`string`	Direct Debit	test
CrDay	`string`	Credit Days	100
PaidAmt	`string`	The sum of amount which have been paid in advance	10000
PaymtDue	`string`	Outstanding amount that is required to be paid	5000

Reference Details

Param	Type	Description	Example
InvRm	`string`	Remarks/Note	TEST
DocPerdDtls	`json object`	Invoice Period Details

Invoice Period Details

Param	Type	Description	Example
InvStDt	`string`	Invoice Period Start Date	01/08/2020
InvEndDt	`string`	Invoice Period End Date	01/09/2020

Preceding Document/Invoice Details

Param	Type	Description	Example
InvNo	`string`	Reference of original invoice, if any	DOC/002
InvDt	`string`	Date of preceding invoice	01/08/2020
OthRefNo	`string`	Other Reference	123456

Contract Details

Param	Type	Description
RecAdvRefr	`string`	Receipt Advice No.	Doc/003
RecAdvDt	`string`	Date of receipt advice	01/08/2020
Abc001TendRefr	`string`	Lot/Batch Reference No.	Abc001
ContrRefr	`string`	Contract Reference Number	Co123
ExtRefr	`string`	Any other reference	Yo456
ProjRefr	`string`	Project Reference Number	Doc-456
PORefr	`string`	PO Reference Number	Doc-789
PORefDt	`string`	POReferencedate	01/08/2020

Additional Document Details

Param	Type	Description	Example
Url	`string`	Supporting document URL
Docs	`string`	Supporting document in Base64 Format
Info	`string`	Any additional information	Document Test

Export Details

Param	Type	Description	Example
ShipBNo	`string`	Shipping Bill No.	A-248
ShipBDt	`string`	Shipping Bill Date	01/08/2020
Port	`string`	Port Code.	INABG1
RefClm	`string`	Claiming Refund `Y` - Yes, `N` - No	N
ForCur	`string`	Additional Currency Code	AED
CntCode	`string`	Country Code	AE
ExpDuty	`string`	Export Duty	null

E-Way Bill Details

Param	Type	Description	Example
TransId	`string`	Transin/GSTIN	12AWGPV7107B1Z1
TransName	`string`	Name of the transporter	XYZ EXPORTS
TransMode	`string`	Mode of transport: `1` - Road `2` - Rail `3` - Air `4` - Ship	1
Distance	`string`	Distance between source and destination PIN codes	100
TransDocNo	`string`	Transport Document Number	DOC01
TransDocDt	`string`	Transport Document Date	18/08/2020
VehNo	`string`	Vehicle Number	ka123456
VehType	`string`	Vehicle Type: `O`-ODC (Overdimentional Cargo) `R`- Regular	R

Sample CURL Request

{
    "Version": "1.1",
    "TranDtls": {
        "TaxSch": "GST",
        "SupTyp": "B2B",
        "RegRev": "Y",
        "EcmGstin": null,
        "IgstOnIntra": "N"
    },
    "DocDtls": {
        "Typ": "INV",
        "No": "DOC/121101",
        "Dt": "18/08/2022"
    },
    "SellerDtls": {
        "Gstin": "24AAAPI3182M002",
        "LglNm": "NIC company pvt ltd",
        "TrdNm": "NIC Industries",
        "Addr1": "5th block, kuvempu layout",
        "Addr2": "kuvempu layout",
        "Loc": "GANDHINAGAR",
        "Pin": 382008,
        "Stcd": "24",
        "Ph": "9000000000",
        "Em": "[email protected]"
    },
    "BuyerDtls": {
        "Gstin": "29AWGPV7107B1Z1",
        "LglNm": "XYZ company pvt ltd",
        "TrdNm": "XYZ Industries",
        "Pos": "12",
        "Addr1": "7th block, kuvempu layout",
        "Addr2": "kuvempu layout",
        "Loc": "GANDHINAGAR",
        "Pin": 562160,
        "Stcd": "29",
        "Ph": "91111111111",
        "Em": "[email protected]"
    },
    "DispDtls": {
        "Nm": "ABC company pvt ltd",
        "Addr1": "7th block, kuvempu layout",
        "Addr2": "kuvempu layout",
        "Loc": "Banagalore",
        "Pin": 562160,
        "Stcd": "29"
    },
    "ShipDtls": {
        "Gstin": "29AWGPV7107B1Z1",
        "LglNm": "CBE company pvt ltd",
        "TrdNm": "kuvempu layout",
        "Addr1": "7th block, kuvempu layout",
        "Addr2": "kuvempu layout",
        "Loc": "Banagalore",
        "Pin": 562160,
        "Stcd": "29"
    },
    "ItemList": [
        {
            "SlNo": "1",
            "PrdDesc": "Rice",
            "IsServc": "N",
            "HsnCd": "1001",
            "Barcde": "123456",
            "Qty": 100.345,
            "FreeQty": 10,
            "Unit": "BAG",
            "UnitPrice": 99.545,
            "TotAmt": 9988.84,
            "Discount": 10,
            "PreTaxVal": 1,
            "AssAmt": 9978.84,
            "GstRt": 12.0,
            "IgstAmt": 1197.46,
            "CgstAmt": 0,
            "SgstAmt": 0,
            "CesRt": 5,
            "CesAmt": 498.94,
            "CesNonAdvlAmt": 10,
            "StateCesRt": 12,
            "StateCesAmt": 1197.46,
            "StateCesNonAdvlAmt": 5,
            "OthChrg": 10,
            "TotItemVal": 12897.7,
            "OrdLineRef": "3256",
            "OrgCntry": "AG",
            "PrdSlNo": "12345",
            "BchDtls": {
                "Nm": "123456",
                "ExpDt": "01/08/2020",
                "WrDt": "01/09/2020"
            },
            "AttribDtls": [
                {
                    "Nm": "Rice",
                    "Val": "10000"
                }
            ]
        }
    ],
    "ValDtls": {
        "AssVal": 9978.84,
        "CgstVal": 0,
        "SgstVal": 0,
        "IgstVal": 1197.46,
        "CesVal": 508.94,
        "StCesVal": 1202.46,
        "Discount": 10,
        "OthChrg": 20,
        "RndOffAmt": 0.3,
        "TotInvVal": 12908,
        "TotInvValFc": 12897.7
    },
    "PayDtls": {
        "Nm": "ABCDE",
        "AccDet": "5697389713210",
        "Mode": "Cash",
        "FinInsBr": "SBIN11000",
        "PayTerm": "100",
        "PayInstr": "Gift",
        "CrTrn": "test",
        "DirDr": "test",
        "CrDay": 100,
        "PaidAmt": 10000,
        "PaymtDue": 5000
    },
    "RefDtls": {
        "InvRm": "TEST",
        "DocPerdDtls": {
            "InvStDt": "01/08/2020",
            "InvEndDt": "01/09/2020"
        },
        "PrecDocDtls": [
            {
                "InvNo": "DOC/002",
                "InvDt": "01/08/2020",
                "OthRefNo": "123456"
            }
        ],
        "ContrDtls": [
            {
                "RecAdvRefr": "Doc/003",
                "RecAdvDt": "01/08/2020",
                "TendRefr": "Abc001",
                "ContrRefr": "Co123",
                "ExtRefr": "Yo456",
                "ProjRefr": "Doc-456",
                "PORefr": "Doc-789",
                "PORefDt": "01/08/2020"
            }
        ]
    },
    "AddlDocDtls": [
        {
            "Url": "https://einv-apisandbox.nic.in",
            "Docs": "Test Doc",
            "Info": "Document Test"
        }
    ],
    "ExpDtls": {
        "ShipBNo": "A-248",
        "ShipBDt": "01/08/2020",
        "Port": "INABG1",
        "RefClm": "N",
        "ForCur": "AED",
        "CntCode": "AE",
        "ExpDuty": null
    },
    "EwbDtls": {
        "TransId": "12AWGPV7107B1Z1",
        "TransName": "XYZ EXPORTS",
        "Distance": 100,
        "TransDocNo": "DOC01",
        "TransDocDt": "18/08/2020",
        "VehNo": "ka123456",
        "VehType": "R",
        "TransMode": "1"
    }
}

❗️
Test Environment Not Available

Response

Param	Type	Description	Example
AckNo	`num`	Transaction number	112010000002315
AckDt	`string`	Date and time on which invoice is registered(Date format is "yyyy-MM-dd HH:mm:ss ").	2020-08-05 15:18:00
Irn	`string`	SHA256 hash of Gstin, DocDtls.No, DocDtls.Typ, financial year of DoctDtls.Dt	11f8ef701fe294d4a14aad0b12457e62775d0fdc41a0acf05b74fbb2ddc47acb
SignedInvoice	`string`	Complete e-Invoice data digitally signed using JSON Web Token(JWT) and JSON Web Signature (JWS) with "SHA256RSA" algorithm	eyJhbGciOiJSUzI1NiIsImtpZCI6IjExNUY0NDI2NjE3QTc5MzhCRTFCQTA2REJFRTkxQTQyNzU4NEVEQUIiLCJ0eXAiOiJKV1QiLCJ4NXQiOiJFVjlFSm1GNmVUaS1HNkJ0dnVrYVFuV0U3YXMifQ.eyJkYXRhIjoie1wiQWNrTm9cIjoxMTIwMTAwMDAwMDIzMTUsXCJBY2tEdFwiOlwiMjAyMC0wOC0wNSAxNToxODowMFwiLFwiSXJuXCI6XCIxMWY4ZWY3MDFmZTI5NGQ0YTE0YWFkMGIxMjQ1N2U2Mjc3NWQwZmRjNDFhMGFjZjA1Yjc0ZmJiMmRkYzQ3YWNiXCIsXCJWZXJzaW9uXCI6XCIxLjAxXCIsXCJUcmFuRHRsc1wiOntcIlRheFNjaFwiOlwiR1NUXCIsXCJTdXBUeXBcIjpcIkIyQlwiLFwiUmVnUmV2XCI6XCJOXCIsXCJJZ3N0T25JbnRyYVwiOlwiWVwifSxcIkRvY0R0bHNcIjp7XCJUeXBcIjpcIklOVlwiLFwiTm9cIjpcIkRELTIwMjAwODA0LTlcIixcIkR0XCI6XCIwNC8wOC8yMDIwXCJ9LFwiU2VsbGVyRHRsc1wiOntcIkdzdGluXCI6XCIzN0FSWlBUNDM4NFExTVRcIixcIkxnbE5tXCI6XCIgQUJDIGNvbXBhbnkgcHZ0IGx0ZFwiLFwiVHJkTm1cIjpcInZpa2FzXCIsXCJBZGRyMVwiOlwiVEUgaFwiLFwiQWRkcjJcIjpcImFiY1wiLFwiTG9jXCI6XCJCYW5nYWxvcmVcIixcIlBpblwiOjUxNTMxMSxcIlN0Y2RcIjpcIjM3XCIsXCJQaFwiOlwiOTczODk3MTk3MFwiLFwiRW1cIjpcInZpa2FzQGdtYWlsLmNvbVwifSxcIkJ1eWVyRHRsc1wiOntcIkdzdGluXCI6XCIxMUFBQUNUMzkwNEYxWlpcIixcIkxnbE5tXCI6XCJYWVogY29tcGFueSBwdnQgbHRkXCIsXCJQb3NcIjpcIjM3XCIsXCJBZGRyMVwiOlwiN3RoIGJsb2NrLCBrdXZlbXB1IGxheW91dFwiLFwiTG9jXCI6XCJHQU5ESElOQUdBUlwiLFwiUGluXCI6NzM3MTAxLFwiU3RjZFwiOlwiMTFcIn0sXCJEaXNwRHRsc1wiOntcIk5tXCI6XCJuYW1lIG9mIHRoZSBjb21wYW55IGZyb20gd2hpY2ggZ29vZHMgZGlzcGF0Y2hlZFwiLFwiQWRkcjFcIjpcImFkZHJlc3NcIixcIkFkZHIyXCI6XCJCYW5nYWxvcmVcIixcIkxvY1wiOlwia3prXCIsXCJQaW5cIjo2OTA1MTMsXCJTdGNkXCI6XCIzMlwifSxcIlNoaXBEdGxzXCI6e1wiR3N0aW5cIjpcIjMyRElVUFAxMTc1RzFaMVwiLFwiTGdsTm1cIjpcInNoaXAgdHJhZGVcIixcIlRyZE5tXCI6XCJ2aWthc1wiLFwiQWRkcjFcIjpcInNoaXAgYiBub1wiLFwiQWRkcjJcIjpcIkJhbmdhbG9yZVwiLFwiTG9jXCI6XCJCYW5nYWxvcmVcIixcIlBpblwiOjY5MDUxMyxcIlN0Y2RcIjpcIjMyXCJ9LFwiSXRlbUxpc3RcIjpbe1wiSXRlbU5vXCI6MSxcIlNsTm9cIjpcIjFcIixcIklzU2VydmNcIjpcIk5cIixcIlByZERlc2NcIjpcIlN0ZWVsXCIsXCJIc25DZFwiOlwiMTAwMVwiLFwiUXR5XCI6MTAsXCJVbml0XCI6XCJCQUdcIixcIlVuaXRQcmljZVwiOjIwMC4wMCxcIlRvdEFtdFwiOjIwMDAuMDAsXCJEaXNjb3VudFwiOjEwLFwiQXNzQW10XCI6MTk5MC4wMCxcIkdzdFJ0XCI6MTIuMDAsXCJJZ3N0QW10XCI6MjM4LjgsXCJDZ3N0QW10XCI6MCxcIlNnc3RBbXRcIjowLFwiQ2VzUnRcIjo1LFwiQ2VzQW10XCI6OTkuNSxcIkNlc05vbkFkdmxBbXRcIjoxMCxcIlN0YXRlQ2VzUnRcIjoxMixcIlN0YXRlQ2VzQW10XCI6MjM4LjgwLFwiU3RhdGVDZXNOb25BZHZsQW10XCI6NSxcIk90aENocmdcIjoxMCxcIlRvdEl0ZW1WYWxcIjoyNTkyLjF9LHtcIkl0ZW1Ob1wiOjIsXCJTbE5vXCI6XCIyXCIsXCJJc1NlcnZjXCI6XCJOXCIsXCJQcmREZXNjXCI6XCJTdGVlbFwiLFwiSHNuQ2RcIjpcIjEwMDFcIixcIlF0eVwiOjEwLFwiVW5pdFwiOlwiQkFHXCIsXCJVbml0UHJpY2VcIjoyMDAuMDAsXCJUb3RBbXRcIjoyMDAwLjAwLFwiRGlzY291bnRcIjoxMCxcIkFzc0FtdFwiOjE5OTAuMDAsXCJHc3RSdFwiOjEyLjAwLFwiSWdzdEFtdFwiOjIzOC44LFwiQ2dzdEFtdFwiOjAsXCJTZ3N0QW10XCI6MCxcIkNlc1J0XCI6NSxcIkNlc0FtdFwiOjk5LjUsXCJDZXNOb25BZHZsQW10XCI6MTAsXCJTdGF0ZUNlc1J0XCI6MTIsXCJTdGF0ZUNlc0FtdFwiOjIzOC44MCxcIlN0YXRlQ2VzTm9uQWR2bEFtdFwiOjUsXCJPdGhDaHJnXCI6MTAsXCJUb3RJdGVtVmFsXCI6MjU5Mi4xfSx7XCJJdGVtTm9cIjozLFwiU2xOb1wiOlwiM1wiLFwiSXNTZXJ2Y1wiOlwiTlwiLFwiUHJkRGVzY1wiOlwiU3RlZWxcIixcIkhzbkNkXCI6XCIxMDAxXCIsXCJRdHlcIjoxMCxcIlVuaXRcIjpcIkJBR1wiLFwiVW5pdFByaWNlXCI6MjAwLjAwLFwiVG90QW10XCI6MjAwMC4wMCxcIkRpc2NvdW50XCI6MTAsXCJBc3NBbXRcIjoxOTkwLjAwLFwiR3N0UnRcIjoxMi4wMCxcIklnc3RBbXRcIjoyMzguOCxcIkNnc3RBbXRcIjowLFwiU2dzdEFtdFwiOjAsXCJDZXNSdFwiOjUsXCJDZXNBbXRcIjo5OS41LFwiQ2VzTm9uQWR2bEFtdFwiOjEwLFwiU3RhdGVDZXNSdFwiOjEyLFwiU3RhdGVDZXNBbXRcIjoyMzguODAsXCJTdGF0ZUNlc05vbkFkdmxBbXRcIjo1LFwiT3RoQ2hyZ1wiOjEwLFwiVG90SXRlbVZhbFwiOjI1OTIuMX1dLFwiVmFsRHRsc1wiOntcIkFzc1ZhbFwiOjU5NzAuMCxcIkNnc3RWYWxcIjowLFwiU2dzdFZhbFwiOjAsXCJJZ3N0VmFsXCI6NzE2LjQsXCJDZXNWYWxcIjozMjguNSxcIlN0Q2VzVmFsXCI6NzMxLjQsXCJSbmRPZmZBbXRcIjowLFwiVG90SW52VmFsXCI6Nzc3Ni4zfSxcIlJlZkR0bHNcIjp7XCJJbnZSbVwiOlwiMTIzXCIsXCJQcmVjRG9jRHRsc1wiOlt7XCJJbnZOb1wiOlwiQUJDXCIsXCJJbnZEdFwiOlwiMDIvMDIvMjAyMFwiLFwiT3RoUmVmTm9cIjpcIjEyQVwifV0sXCJDb250ckR0bHNcIjpbe1wiUmVjQWR2UmVmclwiOlwiMTIzXCIsXCJSZWNBZHZEdFwiOlwiMTIvMDIvMjAyMFwiLFwiVGVuZFJlZnJcIjpcImFiY1wiLFwiQ29udHJSZWZyXCI6XCJhYmNcIixcIkV4dFJlZnJcIjpcImFiY1wiLFwiUHJvalJlZnJcIjpcImFiY1wiLFwiUE9SZWZyXCI6XCJhYmNcIixcIlBPUmVmRHRcIjpcIjEyLzAyLzIwMjBcIn1dfSxcIkFkZGxEb2NEdGxzXCI6W3tcIlVybFwiOlwiaHR0cHM6Ly9laW52LWFwaXNhbmRib3gubmljLmluL2dzdGNvcmVfdGVzdC92MS4wMS9pbnZvaWNlXCIsXCJEb2NzXCI6XCJ2aWthc1wiLFwiSW5mb1wiOlwidmlrYXNcIn1dLFwiRXdiRHRsc1wiOntcIlRyYW5zSWRcIjpcIjEyQVdHUFY3MTA3QjFaMVwiLFwiVHJhbnNOYW1lXCI6XCJYWVogRVhQT1JUU1wiLFwiVHJhbnNNb2RlXCI6XCIxXCIsXCJEaXN0YW5jZVwiOjEwMCxcIlRyYW5zRG9jTm9cIjpcIkRPQzAxXCIsXCJUcmFuc0RvY0R0XCI6XCIwNC8wOC8yMDIwXCIsXCJWZWhOb1wiOlwia2ExMjM0NTZcIixcIlZlaFR5cGVcIjpcIlJcIn19IiwiaXNzIjoiTklDIn0.oesnTXdXgOEeRjYr6bRQ-_Ks-bnIpwtj7Zx8phzfjL6vsfuGqBokILz6ai0NHFKRxiX_bTLrgrWmwXyBdEFmt88myf4n-NP5JvwqFx4OIf0gYMFTKGLx4AQsxwXER836FDxyS33K_7Erkm7_yHsITR5sBkYrZYOWimYl5cgh4EFN2mEq0B8oIp9pSXAU2RGvuirV6Rnl902sWj1Zv_2UK8e9C7cS7maeuFvEgAHrwBjxqLVvRGDz93oRVgQcavhdNTmBr8LQo2yRQkwtZKCMY_NGDsIoJx3orAKEUE7D1RbAM6xh-uxGOlqxur50826y0sk6OuG2WB9K5g5gumxIpg
SignedQRCode	`string`	Complete QR- Code data digitally signed using JSON Web Token(JWT) and JSON Web Signature (JWS) with "SHA256RSA" algorithm	eyJhbGciOiJSUzI1NiIsImtpZCI6IjExNUY0NDI2NjE3QTc5MzhCRTFCQTA2REJFRTkxQTQyNzU4NEVEQUIiLCJ0eXAiOiJKV1QiLCJ4NXQiOiJFVjlFSm1GNmVUaS1HNkJ0dnVrYVFuV0U3YXMifQ.eyJkYXRhIjoie1wiU2VsbGVyR3N0aW5cIjpcIjM3QVJaUFQ0Mzg0UTFNVFwiLFwiQnV5ZXJHc3RpblwiOlwiMTFBQUFDVDM5MDRGMVpaXCIsXCJEb2NOb1wiOlwiREQtMjAyMDA4MDQtOVwiLFwiRG9jVHlwXCI6XCJJTlZcIixcIkRvY0R0XCI6XCIwNC8wOC8yMDIwXCIsXCJUb3RJbnZWYWxcIjo3Nzc2LjMsXCJJdGVtQ250XCI6MyxcIk1haW5Ic25Db2RlXCI6XCIxMDAxXCIsXCJJcm5cIjpcIjExZjhlZjcwMWZlMjk0ZDRhMTRhYWQwYjEyNDU3ZTYyNzc1ZDBmZGM0MWEwYWNmMDViNzRmYmIyZGRjNDdhY2JcIn0iLCJpc3MiOiJOSUMifQ.fya8oD85f2_K8pDWSf8N94_T24O1lA9OPpIuUwk14el_r1lhL13OFxGkklhiewSMUom8DvO9JKu4jjz2l5farRTJhiBWJ43EtEky2SLzRhJf23JYW_6PyLErYL2RTzv2PlZ75eXIBZzPkxc2erCx61T50oHmExLgl1Q6HclvgiQUAVxysq1VFv96zEZVH8I0xDNqjdvqdtsW74ZHqzpV28kDIvuyV4Z5j3bR39GE6YKMetext_x3bJ4Wt4F1z3DOzfUjuKGdEjP0fTSwNg1RpiDoH4wcaMP7RJgtbQYXn4j3YoppCEw916AmbihiT2gSODPn04vhCbBecI7oOZvxpw
Status	`string`	"ACT" for Active and "CNL" for Cancelled	ACT
EwbNo	`num`	E Way Bill No. , if E Way Bill is generated	191008688443
EwbDt	`string`	E Way Bill Date. , if E Way Bill is generated	2020-08-05 15:18:00
EwbValidTill	`string`	E Way Bill validity date, if Part B details are provided in the payload	2020-08-06 23:59:00
Remarks	`string`	Remarks if any	null

Response Caching

Response caching is not available for this API. Learn more about our response caching mechanism here

Wallet Charges

Since Generate IRN API is a Paid API, a wallet charge will take place.

Versioning

This API is currently in major version 1.0. Refer to our versioning policies here

Overview

Endpoint

Request

Headers

Body Parameters

Transaction Details

Document/Invoice Details

Seller Details

Buyer Details

Dispatch Details

Shipping Details

Item List

Batch Details

Attribute Details

Invoice Value Details

Payment Details

Reference Details

Invoice Period Details

Preceding Document/Invoice Details

Contract Details

Additional Document Details

Export Details

E-Way Bill Details

❗️Test Environment Not Available

Response

Response Caching

Wallet Charges

Versioning

❗️
Test Environment Not Available
