Generate QR String
QR code requires a QR string which the scanner interprets to fetch information. Businesses can generate QR strings using Sandbox APIs to top-up virtual bank accounts.
Overview
This API generates a QR string which can be encoded into a QR code to add funds to your virtual account by passing account_number
and payment_details
entity.
Problem
- The requirement to easily add funds to a virtual bank account.
Solution
- API to generate the QR String, which can be encoded into the desired QR code that users can scan to add funds to their Virtual Bank Account.
Sequence Diagram
Endpoint
HTTP Method | Resource |
---|---|
POST | /tax-payment/accounts/{account_number}/upi/qr |
Request
Follow the below guidelines to pass the account number in the path parameter, and the payment details entity as the body, with the option of passing static in the query parameter.
Path Parameter
Param | Type | Description | Example |
---|---|---|---|
account_number | string | Virtual bank account number from which you want to add funds to. | HEY564578321596 |
Query Parameter
Param | Description | Example |
---|---|---|
static | used to generate static or dynamic QR. Possible values: - true - false Default value is set to false | false |
Body
The payment details entity is passed into the body.
Sample CURL Request
curl --request POST \
--url 'https://api.sandbox.co.in/tax-payment/accounts/xxxxxxxxxxxxxxx/upi/qr?static=false' \
--header 'Accept: application/json' \
--header 'Authorization: xxxxxxxxxxxxxxx' \
--header 'Content-Type: application/json' \
--header 'x-api-key: xxxxxxxxxx' \
--data '
{
"@entity": "payment",
"payment_details": {
"@entity": "payment_details",
"description": "Payment Request For Order: 12345678 ",
"notes": {},
},
"amount": 100
}
'
Different Types of UPI QR strings.
Static - A static QR string can be used to collect multiple payments on a single QR string.
- These QRs are similar to what are being used by local shops and vendors to collect payments from a retail customer.
Dynamic - A dynamic QR string can be used to collect exactly one payment on a single QR string.
- For each transaction, a customer has to create a new QR code, and each QR code will have a unique
transaction Id associated with it, which can be used to reconcile transaction postback on successful
payment.- These QRs are similar to what is being used in payment gateways.
Test Environment Not Available
Response
Params | Type | Description | Example |
---|---|---|---|
qr_string | string | The QR string should be encoded into a QR code. | upi://pay?pa=hiquicko@icici&pn=Quicko&tr=EZV2021100412035600027120&am=10&cu=INR&mc=5411&tn=Payment Request For Order: 12345678 |
static | boolean | It signifies if the QR sorting is static or dynamic | True, False |
transaction_id | string | It signifies the transaction id for a dynamic QR string. | 58sdKG-12e4-5d58-8c4s5654sw6898 |
Response Caching
Response caching is not available for this API. Learn more about our response caching mechanism here
Wallet Charges
Since Generate QR String API is a Paid API, a wallet charge will take place.
Versioning
This API is currently in major version 1.0. Refer to our versioning policies here
Updated 9 months ago
